STATIM'S SPEED

Reduces Instrument Investment

STATIM sterilizes handpieces and instruments for immediate use in as little as 8 minutes, reducing the number required as instruments can be processed ‘just in time’ or between patients.



Increases Efficiency

Fast point-of-use sterilization makes turnaround a priority, increasing efficiency and virtually eliminates instrument bottlenecks.



Gentle on Instruments

Our state-of-the-art steam technology is gentle on both solid and hollow instruments.



THE STATIM DIFFERENCE.

Immediate Steam Generation

Unlike conventional autoclaves that need to heat an entire reservoir of water, STATIM uses only a small, specific amount of water required for each cycle. Water is introduced into a heating device referred to as a ‘steam generator’, rapidly heated and converted to steam in mere seconds.



Air Removal

Using PPPD technology and our patented steam injection process – air is automatically forced out of the sterilization chamber.



Cassette System

The thin stainless steel walls of STATIM’s fully-removable cassette, (or sterilization chamber) allow for rapid heating and cooling of the chamber. As a result, STATIM meets the conditions for sterilization and drying in a fraction of the time required by a conventional autoclave.



Drying Technology

The STATIM 2000 and 5000 have each been designed to provide you with a complete solution: rapid sterilization balanced by rapid drying. Introducing STATIM Dri-Tec drying technology.

TOUCH. CONNECT. PROTECT. COLLECT.



Touch

A large 3.5” high-resolution touchscreen offers a vivid display of messages, current cycle information and customizable colours all with extraordinary clarity. Fully adjustable contrast levels let you optimize the screen to the lighting in your steri-centre.



Connect

Through your networked portal, you can vie not only your STATIMs current operations in real time, you can also access cycle history, printing and validation information, and also sterilization records. Capable of sending emails with cycle information errors directly to your dealer, your STATIM G4 will let qualified technicians know when service is imminent.



Protect

Patient safety relies on attention to detail. The STATIM G4 supports verifiable processes that are PIN protected with user-defined IDs so that staff members can be required to authorize a cycle. This encourages extra attention to process and creates a safer environment for both staff and patients.



Collect

An undocumented sterilization cycle might as well not have been performed. With each cycle, information must be stored to protect your office and your patient. The integrated DataLogger stores all cycle information for the lifetime of the unit, which is accessible through multiple channels such as: a USB port for manual retrieval; an Ethernet connection for web based archiving or desktop printing; or a RS232 port for an external printer option.

  • Cassette autoclave
  • Unprecedented ease of use, putting you in control
  • Ultra-fast condition phase
  • Rapid sterilisation balanced by rapid drying
  • PPPD technology and patented steam injection process – air is automatically forced out of the sterilisation chamber
  • The thin stainless steel walls of the fully-removable cassette allow for rapid heating and cooling of the chamber
Videos

How to perform a daily automatic control test (ACT)

How to perform a daily automatic control test (ACT)

Recommissioning your decon room post COVID-19

)

Detailed below is a list of errors which may occur. Click on an error to see what this means and what action should be taken.

If you do not find the problem below or the action you take does not solve the problem, please contact our support team on 08700 10 20 46. In order to help you, have the serial number of your autoclave and a detailed description of the fault ready.

Unit does not power ON

Action

Check that the unit is plugged into a properly grounded outlet and that the power cord is firmly seated at the rear of the machine.

Try another circuit. Power unit OFF for 10 seconds and then power ON again. Check the condition of the line circuit breaker or fuse.

There is water under the machine

Action

Check that water was not spilled when refilling the reservoir. Make sure the plug in the exhaust tube is secured. Remove and reinsert the cassette. Attempt another cycle.

 The metal parts will be hot and the cassette will contain hot steam.

The cassette is leaking. If water drips from the underside of the unit during operation, check the cassette seal for misalignment or damage and replace the seal if required.

 The metal parts will be hot and the cassette will contain hot steam.

Attempt another cycle. If it still leaks attempt another cycle using a different cassette.

If the leak persists, turn the unit OFF, remove and unload the cassette, unplug the unit, and call our service team on 0800 028 4749.

Instruments do not dry

Action

Best drying occurs when the cycle continues to completion. Allow the cycle to finish. Make sure the instruments are loaded correctly in the cassette. Refer to section 4. Using Cassettes and Preparing Instruments of the Statim 2000 User Manual.

Check the unit levelling.

Check air/biological filters and replace if dirty. Clean the inside of the cassette and treat with STAT-DRI Plus drying agent. Refer to section 8.1 Cleaning the Cassette of the Statim 2000 User Manual. Examine the exhaust tube (tube to the waste bottle) for kinks.

If kinked, straighten the tube. If the tube cannot be straightened remove it from the push-in fitting attached to the STATIM. Depress the collar on the fitting and with the other hand pull firmly on the tube. Once the tube is free of the fitting, cut the damaged section of tubing away using a sharp instrument. Be sure that you leave enough tube to reach the unit when you re-attach the tube to the exhaust fitting. If the tube is too short to remove a section, contact our service team on 0800 028 4749 for a replacement.

Make sure the compressor is working. To check, remove the exhaust tube from the waste bottle. Start the Air Drying Only Cycle and place the free end into a glass of water. If there is not a strong steady flow of bubbles, the compressor is not functioning properly. Call our service team on 0800 028 4749.

Cycle interrupted "“ NOT STERILE or Cycle aborted "“ NOT STERILE and CYCLE FAULT message

Action

Wait a few minutes and attempt another cycle before proceeding to the next solution. Remove the cassette.

 The metal parts will be hot and the cassette will contain hot steam.

Inspect the cassette to ensure that the holes in the back of the seal are perfectly aligned, and that the flexible lip of the seal is completely free. Check the exhaust tube for kinks or obstructions. If kinked, straighten the tube.

If the tube cannot be straightened, remove it from the push-in fitting attached to the STATIM. Depress the collar on the fitting and with the other hand pull firmly on the tube. Once the tube is free of the fitting, cut the damaged section of tubing away using a sharp instrument. Be sure that you leave enough tube to reach the unit when you re-attach the tube to the exhaust fitting. If the tube is too short to remove a section, contact our service team on 0800 028 4749 for a replacement.

Check that the STATIM has not inadvertently been exposed to any electrical interference. Refer to section 3.1 Positioning your Unit of the Statim 2000 User Manual.

Try running another cycle. If the problem persists, record the cycle fault message number and contact our service team on 0800 028 4749.

Excessive steam from the front of the machine

  Action

Remove and reinsert the cassette. Attempt another cycle. Remove and check the cassette seal for misalignment or damage. Replace the seal if required.

 Be careful as the metal parts will be hot and the cassette will contain hot steam.

If the leak persists, turn the unit OFF, remove and unload the cassette and contact our service team on 0800 028 4749.

The printer does not work

Action

Make sure that the printer cable is connected securely with the connector on the back of the STATIM. Make sure that the printer is powered ON. Power unit OFF for 10 seconds and then power ON again.

Time and date are incorrect

Action

The time and date have not been set. See section 3. Setting up your STATIM of the Statim 2000 User Manual for time and date instructions.

Touchscreen is blank/white

Action

Power was interrupted during a firmware upgrade.

Power off the unit and power it on again.

It can take up to 6 minutes before the main menu screen appears.

Touchscreen is blank/dark

Action

Check power source.

USB storage device does not contain the last print out

Action

Re-insert the USB storage device and wait for the data to copy over again. If problem persists, back up all the information you have on the USB device and reformat it. You can always access all your unit’s cycle information through the unit’s web portal.

Unit is not sending emails

Action

Check email settings by using the TEST button on the unit’s web portal. From the SETUP web page, select the TOOLS tab. Click on TEST to check your router, unit and internet connections. If all settings appear to be OK, go to the unit’s touchscreen and renew the IP address by following these steps:

  • Scroll through the setup menu to NETWORK SETUP and select.
  • Select RENEW IP.

Not receiving emails from the unit

Action

Check your spam filter. Be certain the unit has been identified as an accepted email source. Ensure that you have accepted the SciCan Privacy policy by putting a check mark in the box on the CONTACTS page of your web portal.

Machine will not start and touchscreen displays H2O X icon

Action

Press on the icon    to confirm whether it is a water level problem or a water quality problem.

If it is a water quality problem, you have likely used water which is not steam-process distilled or is improperly distilled.

If the level of the water in the reservoir is low, refill the reservoir.

Filling the Water Reservoir

When filling the reservoir, ensure you only use steam processed distilled water containing less than 5ppm total dissolved solids (having conductivity of less then 10µS/cm). The impurities and additives in other water sources will cause an error reading on the LCD. To fill the reservoir, follow the steps below:

  1. Remove the reservoir cap (1).
  2. Pour steam-process distilled water into the reservoir until almost full (a maximum of 4 litres). Use a funnel to avoid spillage.
  3. Replace and secure the cap.

Empty the reservoir and refill with steam-process distilled water containing less than 5 ppm total dissolved solids (having conductivity of less than 10 μS / cm).

If you have the water conductivity meter, check the quality of the water before refilling the reservoir.

To empty the reservoir follow these steps:

  1. Place a water container below the unit.
  2. Using the drain tube (see Section 3.5 Priming the Pump, Figure 6 of the Statim 2000 User Manual) empty the contents of the reservoir into the water container.
  3. Remove any remaining water from the reservoir with a non-linting, absorbent towel.
  4. Screw-in the three leveler feet found underneath the unit.
  5. Repack the unit in the original packing materials and include all accessories originally included with the unit.
  6. Specify heated and insured shipping.

Touchscreen displays the globe icon with X beside it

 Action

An X over the connectivity icon    means the unit is not connected to a network. If it is supposed to be connected to a network and the X is visible, it is because the unit is unable to acquire an IP address.

To resolve the issue, try the following:

  • Check that the router is functioning properly.
  • Check the LAN cable (try a new cable if possible).
  • Make sure your router assigns IP addresses automatically.

Renew the IP address by following these steps:

  1. Scroll through the setup menu to NETWORK SETUP and select.
  2. Select RENEW IP.

How often should you perform the helix test?

Once a day.

How often should you perform the ACT?

Once a day.

How often should you perform the vacuum test?

Once per week on a cold, empty chamber.

Do you need to drain the water from the autoclave at the end of each day?

Yes, no residual water must be left in the unit overnight.

What instruments can you put through on the Quick S programme?

Hollow, solid and air retentive instruments can be put through on this cycle.

Can the autoclave be linked to a drain?

Yes, this requires the purchase of a double chamber syphon and can be fitted by a Henry Schein Dental engineer.

How often should you download the data logger?

This is down to the practice requirements, but typically many practices will download once per week.

My autoclave has a data logger attached; do I still need to carry out the TST test?

Consult the manufacturer of your autoclave as they will inform you if this is required. HTM 01-05 states that this should still be completed. If you obtain no advice from the manufacturer then follow the HTM 01-05 guidance.

Cleaning the Cassette

Keeping the STATIM cassette clean is good clinical practice and assists in the proper functioning of the unit. SciCan recommends that the interior surface be cleaned at least once a week. Cleaning the inside of your cassette is very important if you regularly sterilise lubricated instruments.

  1. Use dishwashing soap or a mild detergent that does not contain chlorine.
  2. Scrub the inside of the cassette with a cleaning pad designed for use with Teflon™ coated surfaces.
  3. After scouring, rinse thoroughly with water to remove all traces of the detergent.

Coating the entire inside surface with STAT-DRI Plus drying agent induces water to form an even coat on the inside surface, without beading. The water in contact with the hot cassette surfaces also evaporates much more efficiently. Spotting is minimised and instruments dry much better. STAT-DRI Plus should be applied every 10 cycles and after every cassette cleaning.


Cleaning the Water Reservoir Filter

This water reservoir filter should be cleaned at least once a week or when required.

The filter can easily be removed and cleaned by placing the filter upside down under running water to wash away the particles until clean and then placed back into the reservoir opening.


Cleaning the Reservoir

Check the reservoir for dirt or particles. The reservoir may be cleaned by draining followed by cleaning and rinsing with steam process distilled water ONLY. Use of chemicals or cleaning agents is not recommended and could damage the unit.


Cleaning the Exterior Surfaces

Use a soft cloth moistened with soap and water to clean all exterior surfaces.

Do not use harsh cleaning chemicals or disinfectants.


Changing the STATIM 2000 G4 Air Filter

The filter should be replaced every six months or after 500 cycles in order to maintain an adequate supply of clean air


 during the air drying cycle.



To change the filter, follow these steps:

  1. Turn the power switch at the back of the unit OFF.
  2. Remove and discard the old foam air filter (3).
  3. Install the new filter (3).
  4. Secure the filter plate (2) to the back of the compressor using the screw (1) retained during the disassembly procedure.

Changing the Bacteria Retentive Air Filters

The filters should be replaced every six months or after 500 cycles to maintain an adequate supply of clean air during the air drying cycle.

To change the bacteria retentive air filter on the STATIM 2000 G4 follow these steps:

  1. Power the STATIM OFF.Image
  2. Disconnect tube A (1) from the bacteria retentive filter (2) and remove the filter from the filter bracket (3). As you remove the filter from the bracket, note the orientation of the arrow mark on the filter.
  3. When the filter is free of the bracket, carefully disconnect tube B (4) from the filter.
  4. Before installing the replacement bacteria retentive filter (2) check that the arrow mark on the filter matches the direction of the arrow on the bracket. Push the left hand filter fitting into tube B (4).
  5. Gently press the replacement filter into the filter bracket (3). The arrow mark of the filter should be facing out and pointing to the left.
  6. Re-connect tube A (1) to the right hand filter fitting.

Replacing the Cassette Seal

To ensure optimum performance of your STATIM cassette autoclave, change the cassette seal every 500 cycles or every six months, whichever comes first.



To change the cassette seal, follow these steps:

Place the cassette lid and the new seal on a clean work surface. Examine the position of the old seal in the cassette lid and arrange the new seal in the same orientation, next to the lid.



Remove the old seal and discard. Clean any residue out of the seal channel and flush out the channel with distilled water.


Lubricate the new seal with the liquid seal lubricant provided.


Insert the rounded edge of the seal under the round lip of the lid. Align the holes in the new seal with the holes in the lid.

At every corner and at the holes in the lid, two square nibs should be visible. The nibs should fit flush with the lid’s outer surface.


Ensure the seal is completely inserted. Feel around the periphery to ensure the seal is securely in place.

 During a cycle, steam may appear between the lid and the tray. If this persists, remove the cassette and check that the seal is correctly installed.

The metal parts will be hot and the cassette may contain hot steam.


Maintaining Fluid Levels

  1. The water reservoir level is continually monitored by your STATIM. If the reservoir is low, a red X will appear on the water icon  Image of the cycle select screen. Press the icon to go to the next screen to confirm that it is a water level issue and not a water quality issue.
  2. If the reservoir is low, a Image will appear next to WATER LEVEL.
  3. To fill the reservoir, remove the cap from the top of the unit and fill the reservoir.

It is recommended to use a funnel to minimise spills. Each time you refill the reservoir, empty the waste bottle and refill with water to the MIN line. Empty the waste bottle often to avoid unpleasant odours and discolouration of the contents. A low-level chlorine-free disinfectant, prepared according to the manufacturer’s instructions, may be added to the waste bottle to remedy this situation.


Reading Water Quality

  1. The water quality is continually monitored by your STATIM. Use only steam-process distilled water containing less than 5 ppm total dissolved solids (having conductivity of less than 10 μS / cm) in the STATIM. If the water quality is beyond these tolerances, a red X will appear on the water icon Image of the cycle select screen. Press the icon to go to the next screen to confirm that it is a water quality issue and not a water level issue.
  2. If the water quality not suitable, Image will appear next to micro S. and parts per million values.
  3. Using the drain tube (see section 3.5 Priming the Pump, Figure 6 of the Statim 2000 User Manual) empty the contents of the reservoir into the water container and replace with steam-process distilled water containing less than 5 ppm total dissolved solids (having conductivity of less than 10 μS / cm).

Preventative Maintenance Schedules

To ensure trouble-free performance, both the operator and the dealer must follow a preventative maintenance schedule.

Please refer to your National, Regional or Safety laws for any additional reoccurring user testing that may be required.

The schedules below describe the necessary actions.

Operator

Daily

Water Reservoir

Drain after each working day

Waste Bottle

Empty the waste bottle every time you refill the reservoir. Fill with tap water up to MIN line.

You could also add some chlorine-free disinfectant.

Weekly

Cassette

Wash the interior of the cassette with chlorine-free dishwashing detergent or soap.

Rinse thoroughly with water to remove all traces of the detergent and treat interior surfaces of the cassette with the STAT-DRI™ Plus drying agent to enhance the drying process.

Water Filter

Check the water reservoir filter every week and clean if necessary. Replace only if necessary.

Biological and/or Air Filter

Check the filter for dirt and moisture. Replace if dirty. Call our servicing team on 0800 028 4749 if wet.

Every 6 months

Air Filter

Replace every 500 cycles or six months (whichever comes first).

Biological Air Filter

Replace every 500 cycles or six months (whichever comes first).

Cassette Seal

Replace every 500 cycles or six months (whichever comes first).

Technician

Once a year

Cassette

Check the tray, lid and seal for damage. Replace if necessary.

Biological Filter

Inspect the biological filter for moisture.

Solenoid Valve

Inspect the valve and clean if dirty. Replace the plunger if detective.

Pump

Clean the filters, replace if dirty.

Check Valve

Remove the exhaust tube from the back of the unit during the air drying phase. Check for air coming from the fitting.

Remove the air compressor tube from the check valve inlet while running a cycle. Make sure no steam is leaking from the valve. Replace if there are any leaks.

Water Reservoir

Check the reservoir for dirt. Clean and rinse with steam process distilled water if necessary.

Calibration

Calibrate the unit.


Shipping the Unit / Draining the Reservoir

Before you move the unit, you will need to drain the reservoir. To do so, follow these steps:

  1. Place a water container below the unit.
  2. Using the drain tube (see Section 3.5 Priming the Pump, Figure 6) empty the contents of the reservoir into the water container.
  3. Remove any remaining water from the reservoir with a non-linting, absorbent towel.
  4. Screw-in the three leveller feet found underneath the unit.
  5. Repack the unit in the original packing materials and include all accessories originally included with the unit.
  6. Specify heated and insured shipping.

Future-Proof your practice today with our cover options

We know an unexpected breakdown in your practice can be a massive headache for you and your patients - which is why we have a dedicated team of 50 people ready to provide you with a range of comprehensive cover options for your practice equipment, giving you complete peace of mind and minimising the cost of an unexpected breakdownYou can depend on us.

High tech digital support specialists

With Protection Cover, you get free access to our team of 10 high tech digital support specialists who can help with digital imaging, lasers and CAD/CAM. For the simpler problems, we also have technicians, who are dedicated to helping you over the phone. You can also at a small cost, use their services even if you don't have cover.

Protection cover

Invest in your practice - choose our comprehensive protection cover. For 12 months we will cover the items you want. It includes an annual service, emergency breakdown, labour and access to our high tech digital support specialists.

Annual service

To get optimum performance from your equipment and to conform to manufacturer’s recommendations, an annual service could be just what you’re looking for. It’s carried out by our accredited team and includes a 3 month warranty on the work.

Emergency breakdown service

We are never far away in an emergency. Unplanned breakdowns are a headache for any surgery. We are more than happy to help.

Call us today on 0800 028 4749.

Enquire Now

Our equipment team will use the information you provide to respond to your query as promptly as possible.

You could ask about a FREE one-to-one consultation with one of our specialist team, quotation, demonstration of the latest equipment, or any other question you may have in helping you make an informed decision.

Contact Permission (not required)

We’d love to send you exclusive offers and latest news stories from Henry Schein Dental by e-mail. We’ll always treat your personal details with care and will never sell them to other companies for marketing purposes.
